Product Description
Feature
(1)Medium is delivered in axial direction continuously without agitation and pulsation.
(2)Small vibration and low noise
(3)High pressure and high efficiency
(4)Simple structure, easy disassembly and assembly
(5)Small volume and lighe weight
(6)Slight wear and long life of the pump
Structure: The pumps are sealed generally by mechanical seal and driven by the motor through the claw coupling. Or magnetic coupling.
Material: The driving and driven screw 16Mn, 38CrMoAl
Pump casing: HT200, QT450-10
Bush: Aluminum, Nodular Cast Iron, Bronze
>>>Conveying Medium:
1. Clean lubricating liquid, such as lubricant, mineral oil, synthetic hydraulic fluid, natural oil, etc.
2. Medium with worse lubricating property, such as light fuel oil, heavy fuel oil, cool tar, asphalt, viscose, emulsified mixture, etc.
>>>3G Triple Screw Pump Application:
It applies to deliver clean and non-corrosive medium which has lubricating propertty at temperature below 150 deg C with the viscosity of 5-760cst, the pump's working pressure range from 0.6Mpa to 4Mpa and flow rate range from 0.6m3/h to 123m3/h.
They are mainly suited to fuel delivering, hydraulic engineering, shiping engineering, petrochemical and other industry fields.
>>>FAQ--- Frequently Asked Question
1. How to get our quotation in time, please answer following questions:
A.What liquid do you transfer? Oil, Water, Food or Corrosive Chemical liquid, with solid particle or not, and so on~
B. What's the flow or capcity (m3/h, L/m)?
C.What's the discharge head (m, feet, Mpa, bar )
If you do not have any request, we will do as our normal standard.
D. Contact us to get the quotation:
2. OEM: Ok
3. MOQ: 1set
4. Package: Standar export Plywood Case or Styrofoam with Carton
5. Shipping ways: By sea, By air, By express
6. Lead time: 3-15days
7. Term of payment: 100% T/T, Aliexpress, L/C, Westunion
8. Why choose us: more than 20 years experiences manufacturer
Good quality with competitive pirce
ISO2000, CE certificate, CCS certificate
Professional after-sales service
