3G Three Screw Diesel Transfer Pump

  • Model NO.: 3G70X4
  • Screw Suction Method: Single Suction
  • Performance: No Leak
  • Certification: CE, ISO
  • Screw Material: 38CrMoAl
  • Seal: Mechanical Seal
  • Trademark: HOFFWELL
  • Origin: Cn
  • Screw Number: Multi Screw Pump
  • Pump Shaft Position: Horizontal
  • Application: Oil
  • Pump Body Material: Cast Iron Ht200
  • Bush Material: Bronze/Nodular Cast Iron
  • Bearing: SKF Bearing
  • Specification: CE, SGS
  • HS Code: 84136040
Quantity:
>>>Product Features:

1. Good self-priming and suction performance
2. Wide medium range, including liquid with slight lubricity
3. Minimal flow pulse, state operation and small vibration and noise.
4. No shear or damage of the conveyed medium, so the conveyed medium is not easy to be aging.
5. High efficiency, energy saving, high reliability.
6. Long service life, simple maintenance and low cost.


>>> Conveying Medium:

1. Clean lubricating liquid, such as lubricant, mineral oil, synthetic hydraulic fluid, natural oil, etc.
2. Medium with worse lubricating property, such as light fuel oil, heavy fuel oil, cool tar, asphalt, viscose, emulsified mixture, etc.


>>> Example of pump model:


Eg:3G25×4-46
3G:three screw pump
25:out-side dizmeter of the driving screw 25mm
4:potch number of the screw
46:46° pitch angle of the screw
R:hezvy fuel oil
r:light fuel oil
W:high temperature heated oil
N:high visc oil
A:code of design improvement
S:double suction


>>>According to the application modes three screw pump is divided into five series
Series Main application Performancescope
Capacity m3/h Pre MPa
3G Lub oil visc3-20oE;temp≤80ºC 0.6-570 2.5
3GR Heavy feul lil visc3-50oE;temp≤120ºC 0.6-570 2.5
3GR Light feul oil visc1.2-5oE;temp≤120ºC 0.6-570 1.6
3GW High temp feul heated oil;temp≤150ºC 0.6-363 1.6
3GN High visc oil 100oE;temp≤80ºC 0.6-636 2.5

3G Three Screw Diesel Transfer Pump

>>>Performance Parameters

Model Exhaust
Pressure
MPa
Capacity Q Speed
r/min
(NPSH)r
m
Efficiency
η %
Motor
m3/h L/min Power
kw
Model
25×4-46 1.0 0.8 13 1450 4 62 0.75 Y802-4
2.5 0.6 10 60.6 1.5 Y90L-4
1.0 2.0 33 2900 4.5 59.4 1.5 Y90S-2
2.5 1.6 26 69 3 Y100L-2
30×4-46 1.0 1.6 26 1450 4.5 63.5 1.1 Y90S-4
2.5 1.2 20 61 2.2 Y100L1-4
1.0 3.6 60 2900 5 60 2.2 Y90L-2
2.5 3.2 53 69 4 Y112M-2
36×4-46 1.0 2.8 46 1450 4.5 66 2.2 Y100L1-4
2.5 2.4 40 66.5 4 Y112M-4
1.0 6.5 108 2900 5 60.5 4 Y112M-2
2.5 6 100 72 7.5 Y132S2-2
42×4-46 1.0 4.8 80 1450 5 62 4 Y112M-4
2.5 4.2 70 73 5.5 Y132S1-4
1.0 10.5 175 2900 5.5 61 5.5 Y132S1-2
2.5 10 166 72 15 Y160M2-2
45×4-46 1.0 6.3 106 1450 5 70 3 Y100L2-4
2.5 5.9 99 74 7.5 Y132M-4
1.0 13.5 225 2900 5.5 60 7.5 Y132S2-2
2.5 13 217 75 15 Y160M2-2
60×4-46 1.0 15.5 255 1450 5 71.3 11 Y160M-4
2.5 14.5 245 74 15 Y160L-4
1.0 32 533 2900 5.5 63 18.5 Y160L-2
2.5 31.5 525 77 37 Y200L2-2
70×2-46 0.6 24 400 1450 5 71 7.5 Y132M-4
1.0 23.5 390 75 11 Y160M-4
1.6 22.5 370 76 15 Y160L-4
70×4-46 1.0 24.5 408 1450 5 72.5 18.5 Y180M-4
2.5 23.5 392 79 30 Y200L-4
80×2-46 0.6 36.5 608 1450 5 72 11 Y160M-4
1.0 35 594 75.5 18.5 Y180M-4
1.6 34.5 575 76.5 22 Y180L-4
80×4-46 1.0 37 617 1450 5.5 72 30 Y200L-4
2.5 35 590 78.1 45 Y225M-4
100×2-46 0.6 72.5 1208 1450 5 73 22 Y180L-4
1.0 71 1183 77 37 Y225S-4
1.6 60.5 1158 79 45 Y225M-4
100×4-46 1.0 72.5 1208 1450 5.5 73 55 Y250M-4
2.5 70 1165 78.5 75 Y280S-4
S100×3-27 0.6 72 1196 1450 6 62 22 Y180L-4
1.6 70 1160 72 55 Y250M-4
2.5 69 1145 74 75 Y280S-4
S120×3-27 0.8 123 2055 1450 6 74.5 55 Y250M-4
1.5 120 2010 76 90 Y280M-4
2.5 115 1920 78.5 132 Y315M-4
