Cast Iron KCB Cargo Oil External Gear Pump

  • KCB5400
  • HOFFWELL
  • 84136029
Quantity:

KCB Series Cargo Oil External Gear Pump

>>>
Product Features:
1. The pump is properly designed with leakage and return chute, which lets the gears bear the least torque force and reduces load and wear on bearings in order to raise pump's efficiency.
2. Less teeth and small volume; the herringbone tooth structure is of good strained condition, small vibration and puissant.
3. internal installed bearing in pump is lubricated by the conveying medium. So this pump series is just applied to conveying lubricating liquid.


>>>Application:
KCB oil gear pump can give performance as transferpump or booster pump in oil delivery system. It can be also applied as a fuel pump for dilivery system, pressurization and injection in fuel supply system and in all industry fields as lubricating pump. It is univeral type used as lubricant, delivery or supercharge pump in many industry fields.

CE Approved KCB5400 Cargo Oil Gear Pump
>>>Conveyed Medium:
1. Non-corrosive lubricant without solid particles or fiber;
2. Other lubricant like liquids

CE Approved KCB5400 Cargo Oil Gear Pump

>>>KCB5400 Gear Oil Pump Specifications


   Model


Capacity Head     Speed   (NPSH)r   Efficiency    Power Frame Size

 KCB5400


 325m3/h  6bar    989rpm       8m       44%   160KW  Y355M1-6
Packing details 1100mm X 660mm X 1120mm for bare shaft pump, with export standard wooden case.
Delivery time within 15days.


>>KCB5400 Gear Pump Performance Curve


CE Approved KCB5400 Cargo Oil Gear Pump
>>>FAQ
--- Frequently Asked Question

1. How to get our quotation in time, please answer following questions:

 A.What liquid do you transfer? Oil, Water, Food or Corrosive Chemical liquid, with solid particle or not, and so on~

 B. What's the flow or capcity
(m3/h, L/m)?

 C.What's the discharge head (m, feet, Mpa, bar )

 If you do not have any request, we will do as our normal standard.

 D. Contact us to get the quotation:

2. OEM: Ok

3. MOQ: 1set

4. Package: Standar export Plywood Case or Styrofoam with Carton

5. Shipping ways: By sea, By air, By express

6. Lead time: 3-15days

7. Term of  payment:  100% T/T, Aliexpress,  L/C, Westunion

8. Why choose us: more than 20 years experiences manufacturer

                              Good quality with competitive pirce

                              ISO2000, CE certificate, CCS certificate

                              Professional after-sales service


>>>KCB Gear Oil Pump Other Model Parameters:

Model Capacity Q Speed
r/min
Exhaust
Pressure
Mpa
(NPSH)r
m
Efficiency
η %
Motor
m3/h L/min Power
kw
Model
KCB-18.3 1.1 18.3 1400 1.45 5 44 1.5 Y90L-4
2CY-1.1/1.45
KCB-33.3 2 33.3 1420 1.45 5 44 2.2 Y100L1-4
2CY-2/1.45
KCB-55 3.3 55 1400 0.33 7 41 1.5 Y90L-4
2CY-3.3/0.33
KCB-83.3 5 83.3 1420 0.33 7 43 2.2 Y100L1-4
2CY-5/0.33
KCB-135 8 135 940 0.33 5 46 2.2 Y112M-6
2CY-8/0.33
KCB-200 12 200 1440 0.33 5 46 4 Y112M-4
2CY-12/0.33
KCB-300 18 300 960 0.36 5 42 5.5 Y132M2-6
2CY-18/0.36
KCB-483.3 29 483.3 1440 0.36 5.5 42 11 Y160M-4
2CY-29/0.36
KCB-633 38 633 970 0.28 6 43 11 Y160L-6
2CY-38/0.28
KCB-960 58 960 1470 0.28 6.5 43 18.5 Y180M-4
2CY-58/0.28
KCB-1200 72 1200 740 0.6 7 43 37 Y280S-8
KCB-1600 95 1600 980 45 Y280S-6
KCB-1800 112 1800 740 0.6 7.5 43 55 Y315S-8
KCB-2500 150 2500 985 75 Y315S-6
KCB-2850 170 2850 740 0.6 8 44 90 Y315L1-8
KCB-3800 230 3800 989 110 Y315L1-6
KCB-4100 245 4100 743 0.6 8 44 132 Y355M1-8
KCB-5400 325 5400 989 160 Y355M1-6
KCB-5600 330 5600 744 0.6 8 44 160 Y355M2-8
KCB-7600 460 7600 989 200 Y355M3-6
KCB-7000 420 7000 744 0.6 8 44 185 Y355L1-8
KCB-9600 570 9600 989 250 Y355L2-6
